New Plymouth’s coastal terraces and volcanic backdrop tell a story of layered deposition, but the subsurface often holds surprises for engineers. The city’s expansion onto the ring plain of Mount Taranaki means that buried lahar deposits, interbedded tephra, and paleo-channels can change drastically over short distances. Seismic tomography, both refraction and reflection, maps these velocity contrasts without disturbing the ground. We use this method to trace the top of rock beneath the New Plymouth CBD, delineate soft zones where the Waiwhakaiho River once meandered, and provide the shear-wave velocity profiles required under NZS 3404. In our experience across the Taranaki region, combining P-wave refraction with MASW surveys gives a complete picture, while a seismic microzonation study helps planners anticipate how different suburb soils will shake. For sites near the port, where fill overlies marine silts, the tomography cross-sections often reveal the boundary with surprising clarity.
A velocity inversion of less than 400 m/s in the top three metres correlates strongly with the compressible tephra layers we encounter across the Taranaki ring plain.
Methodology and scope
Local considerations
The suburbs of Spotswood and Welbourn, though only a few kilometres apart, sit on markedly different formations. Spotswood, closer to the coast, often has a shallow water table and loose sands that can lose strength during a long-duration earthquake. Welbourn, on higher ground, typically shows weathered volcanics with a stiffer response. Seismic tomography quantifies this difference through Vs30 values, directly feeding into the site classification for structural design. Skipping this step risks applying a uniform foundation strategy across the whole New Plymouth site, which can lead to differential settlement and serviceability cracks. In the Fitzroy area, for instance, buried stream channels filled with soft organic silt have been missed by borehole-only campaigns but stood out clearly as low-velocity anomalies in the refraction tomograms. The cost of ignoring these features often surfaces later as foundation remediation or retaining wall distress.
Applicable standards
NZS 3404: Steel Structures Standard (seismic provisions), NZS 4203: General Structural Design and Design Loadings for Buildings, NZGS Guidelines on Seismic Site Classification, ASTM D5777-18: Standard Guide for Using the Seismic Refraction Method
Associated technical services
Seismic Refraction Tomography for Foundation Design
A 2D P-wave and SH-wave survey to map bedrock depth, rippability, and soil stiffness. Delivers a continuous cross-section ideal for positioning spread footings and assessing the competence of lahar deposits.
Seismic Reflection Profiling for Deep Structure
A high-energy reflection survey targeting horizons beyond 50 metres. Used in New Plymouth to trace fault strands across the ring plain and to map the base of the Quaternary volcanics.
Vs30 and Seismic Site Class Determination
Combined MASW and refraction microtremor survey to calculate the average shear-wave velocity in the top 30 metres, in accordance with NZGS guidelines, for structural design in Spotswood, Welbourn, and the CBD.
Typical parameters
Frequently asked questions
What is the typical cost range for a seismic refraction survey in New Plymouth?
For a standard 115-metre refraction line with 24 geophones, the investment usually falls between NZ$4,990 and NZ$8,640, depending on site access, vegetation clearing, and the number of shot points required to achieve the target depth.
How does seismic tomography help with New Plymouth's specific soil conditions?
New Plymouth sits on the Taranaki ring plain, where layers of volcanic ash, lahar, and paleosol alternate unpredictably. Tomography produces a velocity image that distinguishes stiff breccia from soft, compressible tephra, helping engineers avoid differential settlement and plan appropriate ground improvement.
Can you do a seismic survey in a built-up area like the New Plymouth CBD?
Yes, we adjust the energy source and geophone coupling for urban conditions. An accelerated weight drop replaces explosives, and we schedule work outside peak traffic hours to reduce vibration noise. The survey can be conducted along footpaths and road verges with traffic management in place.
